FD9369

FD9369

VIVOTEK FD9369 is an affordable outdoor dome network camera equipped with a 2M sensor enabling resolution of 1920×1080 at 30 fps. The FD9369 offers a fixed-focus lens for different user scenarios. IR illuminators are equipped with 30-meter effective range for better night visibility. To protect the camera from a range of outdoor environments, the FD9369 is encased in robust IP66 and IK10 rated housing.

We’re always here to help



  1. Need a Customized Solution
  2. Curious About Product Compatibility
  3. Ready To Request a Quote

Our knowledgeable team is available via online chat, phone, or email to assist you with any questions or requests.

Categories: Published On: November 4, 2024

Product Information

Two power input options are available: PoE (Power-over-Ethernet) and DC power, providing users with installation flexibility. In order to facilitate on-board storage and data portability, the camera is also equipped with a MicroSD/SDHC/SDXC card slot for local recording.

The FD9369 uses H.265 compression and employs VIVOTEK’s Smart Stream III technology, which helps to reduce bandwidth and storage consumption. Finally, FD9369 comes with AI based deep-learning smart motion detection to reduce false alarms.

Documents

DATASHEET

Technical Information

General Specifications

  • Model: FD9369
  • Processor: Multimedia SoC (System-on-Chip)
  • Memory: 256 MB Flash, 256 MB RAM

Camera Features

  • Image Sensor: 1/3.1″ Progressive CMOS
  • Max Resolution: 1920×1080 (2MP)
  • Lens Type: Fixed-focal
  • Focal Length: 2.8 mm
  • Aperture: F2.0
  • Iris Type: Fixed iris
  • Field of View:
    • Horizontal: 116°
    • Vertical: 65°
    • Diagonal: 140°
  • Shutter Speed: 1/5 sec. to 1/32,000 sec.
  • WDR Technology: WDR Enhanced
  • Day/Night Functionality: Yes, with removable IR-cut filter
  • IR Illuminators: Built-in, effective up to 30 meters with Smart IR

Low Light Performance

  • Minimum Illumination:
    • 0.08 lux (Color)
    • <0.005 lux (B/W)
    • 0 lux with IR illumination on

Mechanical Specifications

  • Pan Range: 350°
  • Tilt Range: -10° ~ 75°
  • Rotation Range: No rotation (2-axis design)

This camera is well-suited for a variety of surveillance applications, providing a wide field of view and good low-light performance with enhanced WDR technology.
